Designed to run 1 outlet
Exposed design allows easy installation, all working parts are outside of the wall
Centre distance: 150 mm ± 12 mm
Flow rate hand shower connection 12 l/min at 3 bar
Ecostop button limits the water consumption to 10 l/min
Thermostat cartridge, ceramic valve 180°
Safety stop at 40°C
Maximum temperature can be adjusted on installation
With isolated water conduction
Non-return valve
In case of installation on existing G ½ connections, adaptor no. 02026000 must be used
Noise class: I
Dirt filter included
Cannot be connected with a standard fixing plate
WRAS 1301321

Consists of
S-union set (# 95772000)
