2 functions
Projection 216 mm
Connection type: s-shaped connections
Centre distance: 150 ± 12 mm
Spray type mixer: WaterfallStream
Maximum flow rate at 3 bar: 19,4 l/min
Flow rate for bath spout at 3 bar: 19,4 l/min
Min. operating pressure: 1 bar
Max. operating pressure: 10 bar
Ceramic cartridge
Temperature limitation adjustable
Pressure diverter Select with automatic resetting
Intrinsically safe against backflow
With silencer
Suitable for continous flow water heaters
Connection dimension: DN15
