2 functions
Comfortable turning on / off of outlets with large Select-paddle, precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle
Water flow control with stop function
Thermostat cartridge, Start/stop valve to operate the functions
Maximum flow rate at 1 bar: 14 l/min
Maximum flow rate at 3 bar: 26 l/min
Flow rate upper outlet: 23 l/min
Flow rate lower outlet: 23 l/min
Min. operating pressure: 1 bar
Max. operating pressure: 10 bar
Flat escutcheon for more space in the shower
Escutcheon can be aligned by +/- 3°
Easy installation due to pre-assembled function block
Handles always at the same height regardless of the installation depth of the basic set
Safety stop at 40 °C
Temperature limitation adjustable
The thermostat offers the possibility for thermal disinfection
With integrated safety combination EN 1717
Material button: metal
Material handles: metal
Connection type: basic set iBox universal 2 (# 01400180)
Select-paddles are delivered with lasered user symbols (hand shower and bath tub)
Essential Item Required For Installation
