APPLICATION PURPOSES
For metal and wood frame walls
For Geberit Duofix system walls
For installation in part- or room-height prewalls
For installation in room-height partition walls
For floor constructions 0–25 cm
For wall-hung bidets with deck-mounted tap

CHARACTERISTICS
2025 range
Statically self-supporting frame, protected against corrosion with powder coating
With pull-out plate for lateral fastening above the element on metal or wood profiles or on Geberit Duofix system studs
Alternative fastening point for wall anchors
Rotating foot plates, suitable for installation in U profiles UW 50 and UW 75
Foot plates that can be mounted in Geberit Duofix system rail without tools, without additional components
Galvanised non-slip leg supports protected against corrosion
Fastening distance for wall-hung bidet 18 or 23 cm
Height-adjustable bidet fastening
Fastening for connection bend, height-adjustable and soundabsorbing
Tap attachments adjustable in width and height
Self-adhesive sealing washer, fleece-laminated
Protection plug for one-time pressure test with cold water up to a maximum of 15 bar / 1500 kPa

TECHNICAL DATA
Product material Steel

SCOPE OF DELIVERY
2 wall anchors
2 angle stop valves 1/2″
2 elbow tap connectors Rp 1/2″ / R 1/2″, compatible with MF
2 sealing washers
2 sound insulation bases
2 insulating sleeves
Fastening and protection material
