APPLICATION PURPOSES
For metal and wood frame walls
For Geberit Duofix system walls
For installation in part-height prewalls
For floor constructions 0–25 cm
For wall-hung bidets with deck-mounted tap

CHARACTERISTICS
2025 range
Statically self-supporting frame, protected against corrosion with powder coating
Alternative fastening point for wall anchors
Rotating foot plates, suitable for installation in U profiles UW 50 and UW 75
Foot plates that can be mounted in Geberit Duofix system rail without tools, without additional components
Galvanised non-slip leg supports protected against corrosion
Fastening distance for wall-hung bidet 18 or 23 cm
Height-adjustable bidet fastening
Fastening for connection bend, height-adjustable and soundabsorbing
Tap attachments adjustable in width and height
Self-adhesive sealing washer, fleece-laminated
Protection plug for one-time pressure test with cold water up to a maximum of 15 bar / 1500 kPa

TECHNICAL DATA
Product material Steel

SCOPE OF DELIVERY
2 wall anchors
2 angle stop valves 1/2″
2 elbow tap connectors Rp 1/2″ / R 1/2″, compatible with MF
2 sealing washers
2 sound insulation bases
2 insulating sleeves
Fastening and protection material
