APPLICATION PURPOSES
For metal and wood frame walls
For Geberit Duofix system walls
For installation in part- or room-height prewalls
For installation in room-height partition walls
For floor constructions 0–25 cm
For installation of washbasins
For deck-mounted taps

CHARACTERISTICS
2025 range
Statically self-supporting frame, protected against corrosion with powder coating
With pull-out plate for lateral fastening above the element on metal or wood profiles or on Geberit Duofix system studs
Alternative fastening point for wall anchors
Rotating foot plates, suitable for installation in U profiles UW 50 and UW 75
Foot plates that can be mounted in Geberit Duofix system rail without tools, without additional components
Galvanised non-slip leg supports protected against corrosion
Fastening distance for washbasin 5–38 cm
Threaded rods adjustable in depth with 18 or 28 cm fastening distance
Fastening for connection bend, height-adjustable and soundabsorbing
Crossbar for tap adjustable in height and depth
Self-adhesive sealing washer, fleece-laminated
Protection plug for one-time pressure test with cold water up to a maximum of 15 bar / 1500 kPa

TECHNICAL DATA
Product material Steel

SCOPE OF DELIVERY
2 wall anchors
2 angle stop valves 1/2″
2 elbow tap connectors Rp 1/2″ / R 1/2″, compatible with MF
2 sealing washers
Fastening and protection material
