APPLICATION PURPOSES
For metal and wood frame walls
For Geberit Duofix system walls
For installation in part- or room-height prewalls
For installation in room-height partition walls
For floor constructions 0–25 cm
For wall-hung WCs

CHARACTERISTICS
2025 range
Statically self-supporting frame, protected against corrosion with powder coating
Frame for wall-hung WCs with connection dimensions as per EN 33 and projection up to 70 cm
With pull-out plate for lateral fastening above the element on metal or wood profiles or on Geberit Duofix system studs
Alternative fastening point for wall anchors
Rotating foot plates, suitable for installation in U profiles UW 50 and UW 75
Foot plates that can be mounted in Geberit Duofix system rail without tools, without additional components
Galvanised non-slip leg supports protected against corrosion
Connection bend can be mounted without tools at different depths, adjustable range 45 mm
Rotatable connection bend for connection piece for horizontal outlet to the rear
Fastening for electrical connection and Power & Connect Box

TECHNICAL DATA
Product material Steel

SCOPE OF DELIVERY
2 wall anchors
Connection set for WC, ø 90 mm
Connection bend 90° made of PVC, ø 90 / 100 mm
Fastening and protection material
