Shower head size 250 mm
Spout 273 mm long
Spray pattern: PowderRain, Intense PowderRain, RainStream
Middle spray disc: 151 mm
Shower head size: 250 mm
Shower arm vertically inclinable by 10-30°
Maximum flow rate 20 l/min at 3 bar
Flow rate RainStream 16 l/min at 3 bar
Flow rate Rain 18 l/min at 3 bar
Flow rate PowderRain (at 3 bar): 20 l/min at 3 bar
Operating pressure: min. 1.7 bar/max. 10 bar
Tthe 3 spray zones must be controlled via 3 valves or a diverter valve with 3 outlets

EcoSmart version with shower head 250 mm
Spout 273 mm long
Spray pattern: PowderRain, Intense PowderRain, RainStream
Middle spray disc: 151 mm
Shower head size: 250 mm
Shower arm vertically inclinable by 10-30°
Maximum flow rate 9 l/min at 3 bar
Flow rate RainStream 9 l/min at 3 bar
Flow rate Rain 9 l/min at 3 bar
Flow rate PowderRain (at 3 bar): 9 l/min at 3 bar
Operating pressure: min. 1,9 bar/max. 10 bar

Shower head size 360 mm
Spout 381 mm long
Spray pattern: PowderRain, Intense PowderRain, RainStream
Middle spray disc: 205 mm
Shower head size: 360 mm
Shower arm vertically inclinable by 10-30°
Maximum flow rate 28.1 l/min at 3 bar
Flow rate RainStream 16 l/min at 3 bar
Flow rate Rain 18 l/min at 3 bar
Flow rate PowderRain (at 3 bar): 20 l/min at 3 bar
Operating pressure: min. 1.7 bar/max. 10 bar
The 3 spray zones must be controlled via 3 valves or a diverter valve with 3 outlets

Across all shower heads
Select button on thermostat
Spray disc surface: graphite
Spray face: aluminium
Overhead shower removable for cleaning
Frame: metal
Installation: wall-mounted – for installation on iBox

Essential Item Required For Installation
